The following fonts are implemented mainly for being compatible to the stethos sos8026 fontbased barcode product.



OCR A (A1)

The ELP Server traces the data stream for original HP Escape Sequences for OCR A1 (check printing). Once the correct sequence is found, the font is automatically loaded to the printer and activated.

ESC-Sequence HP version "Bar Codes & More": \x1B(0O\x1B(sp10h12vsb104T
ESC-Sequence stethos version: \x1B(___\x1B(s1p###vsb10451T ___ any symbol set ### font size in point
ESC-Sequence HP US version: \x1B(13Y\x1B(s1p###vsb28698T ### font size in point

OCR B

The ELP Server traces the data stream for original HP Escape Sequences for OCR B (Swiss, Austrian address printing, bar code readable text). Once the correct sequence is found, the font is automatically loaded to the printer and activated.

ESC-Sequence HP version "Bar Codes & More": \x1B(1O\x1B(sp10h12vsb110T
ESC-Sequence stethos version: \x1B(___\x1B(s1p###vsb10450T ___ any symbol set ### font size in point
ESC-Sequence Jetmobile BarDIMM version: \x1B(___\x1B(s1p###vsb23590T ___ up to 10 different symbol sets within a print job ### font size in point. German umlauts will only work with symbol sets 1O, 10U, 12U, 18U.
ESC-Sequence HP US version: \x1B(11Y\x1B(s1p###vsb28675T ### font size in point
ESC-Sequence HP US version: \x1B(10Y\x1B(s1p###vsb28684T ### font size in point
ESC-Sequence HP US version: \x1B(13Y\x1B(s1p###vsb28699T ### font size in point

Line Draw

ESC-Sequence: \x1B(0B\x1B(sp10h12vsbT Line Draw of the original Cartridge HP Bar Codes & More

Emergency Symbols

ESC-Sequence: \x1B(10Q\x1B(s1p###vvsb10400T ### font size in point



Green point \x0E\x1B)10Q\x1B)s1p20vsb10400TE\x0F
Green point with text \x0E\x1B)10Q\x1B)s1p20vsb10400TDE\x0F
gray arrows \x0E\x1B)10Q\x1B)s1p20vsb10400Td\x1B*c15G\x1B*v2Te\x1B*vT\x0F
Recycling logo \x0E\x1B(10Q\x1B(s1p20vsb10400Tghij\x08123\x0F
Explosion \x0E\x1B)10Q\x1B)s1p20vsb10400Tst\x0F





Electric and security symbols

ESC-Sequence \x1B(10Q\x1B(s1p###vs3b10400T ### font size in point

Those symbols are part of the font library of Elsner und Flake Fontinform GmbH, Hamburg. Those fonts are only available for the HW solution.


EURO-Symbols

ESC-Sequence: \x1B(s1p###v0s0b10452T ___ any symbol set, ### font size in point

European currency symbol inverse: \x0E\x1B)10U\x1B)s1p20vsb10452TC\x0F

MICR CMC-7

ESC-Sequence stethos version: \x1B(__\x1B(s1p##v0s3b10453T ____ any symbol set, ### Font size in point
ESC-Sequence HP US version: \x1B(8M\x1B(s1p##v0s3b101T ### Font size in point

The control characters after the numerals below are (from left to right and the corresponding character used is enclosed in [ ]) internal [:], terminator [;], amount [<], routing [=], and an unused [>] character.

Usage: This font is used in some countries for check printing.

Example \x1B(10U\x1B(s1p12vs3b10453T<1972675>0013< 0267> 0100027073;

MICR E-13B

ESC-Sequence stethos version: \x1B(__\x1B(s1p##v0s0b10453T ____ any symbol set, ### Font size in point
ESC-Sequence HP US version: \x1B(0Q\x1B(s0p8h8.4v0s0b0T

The control characters bracketing each numeral block are (from left to right and the corresponding character used is enclosed in [ ]) transit [A], on-us [C], amount [B], and dash [D].

Hints:

1) If you encounter that  the MICR font is used in 3 different flavors and only the third sequences matches the MICR font which is included in ELP you can easily map on the fly the ESC sequences. So e.g. for the first sequence:

[Change MICR Sequence 1]
Search_Binary=\x1B(4B\x1B(s1p33.0v0s0b102T
Replace_Binary=\x1B(0Q\x1B(s0p8h8.4v0s0b0T



2) If you want to print CMC-7 or E-13B from SAP and you use the DeviceType HPLJMI:

you might want to map the Print Controls SF451 and SF450:

to the suitable font selection sequences:

[Change CMC-7 MICR_C SF451 Sequence]
Search_Binary=\x1B(8M\x1B(s0p8.00h10.0v0s0b101T
Replace_Binary=\x1B(8M\x1B(s1p10.0v0s3b101T

[Change E-13B MICR_E SF450 Sequence]
Search_Binary=\x1B(8M\x1B(s0p8.00h10.0v0s0b100T
Replace_Binary=\x1B(8M\x1B(s1p10.0v0s0b10453T
